Commercial Stack Tumble Dryers
30 lb capacity - UTT30NV
If you have more laundry than you have floor space, UniMac stack tumblers are the solution for you. These high-performance dryers deliver unmatched efficiency and minimized costs just like standard tumble dryers, but allow you to add 60 or 90 pounds of rated capacity to your on-premises laundry operation without taking up added square footage.
Control OptionsUniLinc Touch
Capacity – lb (kg)30 (13.6)
Width – in (mm)27.9" (710)
Depth – in (mm)45.5" (1155)
Height – in (mm)63.9" (1625)
Cylinder Diameter – in (mm)26.5" (673)
Cylinder Depth – in (mm)31.8" (810)
Cylinder Volume – cu. ft. (liters)9.6 (270)
Door Opening Size – in (mm)22.7" (577)
Heat Input Power73,000 Btu/hr
Gas Inlet Connection – in (mm)*0.5
Air Outlet - in (mm)*6 (150)
Airflow - cfm (liters/sec)*500 (240)
Motor Size – HP (kW)*0.5
Shipping Dimensions Approx.**GasElectric
Width – in (mm)**30.0 (760)30.0 (760)
Depth – in (mm)**49.0 (1240)49.0 (1240)
Height – in (mm)**67.6 (1720)67.6 (1720)
Net Weight – lb (kg)**335 (152)339 (154)
Domestic Shipping Weight – lb (kg)**368 (167)373 (169)
*Field conversions available for LP gas.
**X voltage can be connected to 1 or 3 phase power and operates on 1 phase only
he biggest threat to quality is staff selecting the incorrect wash cycle. UniLinc Touch virtually eliminates that threat with the most intuitive control on the market.
34 languages ensure all staff cannot just operate, but operate it correctly
Real words – no codes – no ambiguity
Easy-to-use, intuitive controls streamline employee training and serve as a virtual laundry manager to ensure maximum labor efficiency (a giant bonus with staff turnover generally being high).
Continuity – same control on washer-extractors and tumble dryers
Ultimate flexibility means your operation is positioned for success well into the future.
Delayed Start – Get a 30-minute head start on the workday with our programmable advanced start feature.
Maximum Energy Efficiency
Each machine is designed to fit through a standard 36-inch doorway, and features a reversible steel doorway making installation flexible and easy.
Lower Utility and Labor Costs
Our stack tumblers achieve the perfect balance between drying temperature, airflow pattern and usable cylinder space for maximum energy efficiency, shortening drying times—and reducing your utility and labor costs.
